Guangzhou Cheng Yin Ming Electronic Technology Co., Ltd.Coaxial acoustics

wily2

Product features:
The ultra high performance drive unit realizes the inherent performance of high efficiency and high power input with high sound pressure and low distortion.
The dual loop technical unit makes the box smaller and solves the problem of time and phase error.
The horn unit is manufactured with custom imported accessories to achieve sound sound expansion and sound pressure.
Convenient and flexible combination of installation, 60 degree slope can be used to monitor the sound box, to adapt to the application of different places.
80 degrees conical cover angle range to distribute high and low frequency energy.
Using symmetrical oblique barrier design, the sound can spread evenly in the horizontal direction, and good sound field uniformity is obtained.
The exterior of the box is treated with black wear spray paint, which is in accordance with the requirements of the environment.
The top of the box with wooden handle, easy to transport and mobile.
The bottom of the sound box is equipped with a scaffold hole, which is convenient to install or integrate with the subwoofer.
Up to 12 M8 hoisting points with adjustable angle hangers are convenient for any way and form of hoisting.
Type: full range two way coaxial loudspeaker (two division frequency)
Material: birch
Frequency response: 50Hz-20KHz (-3dB)
Sensitivity: 100dB 1.0w/1m
Maximum sound pressure level: 125dB (continuous).131dB (peak)
Nominal impedance: 8 Ohm
Rated power: 400W
Peak power: 1600W
Frequency division point: 1.8KHz
Coaxial unit: LOW:1 x 12 "(diameter 75mm sound circle)
HI:1 * 1 "(diameter 44mm inlet)
Coverage angle: 90 (H) x 90 degree (V)
Dimensions: 390 (wide) x 400 (deep) x 520 (high) mm
Weight: 20kg
Connection socket: 2Neutrik NL4MP
Hanging hardware: M8 Rigging point
