For cinephiles who want something more, we proudly introduce our DD+12 subwoofers. They are instantly recognizable as a very serious high end product. Elegantly finished in piano gloss black, our DD+12 subwoofers are stylish and attractive as well as accurate.
For cinephiles looking for uncompromising accuracy in an elegant package, our DD+12 subwoofer is the ultimate choice. It features our ORISUN CORE Direct Servo Technology to ensure accuracy and definition. As an cinephile you appreciate that bass is the foundation of a satisfying home theatre experience. You also appreciate that there is more to a home theatre subwoofer than shaking the room,.
What makes our subwoofers suitable for cinephiles? It's not that they can plumb the depths with authority. There are already many subwoofers on the market which can do that. The difference is that they reproduce bass with a level of realism that is normally only associated with much more expensive high end full range loudspeakers.
- Reference dual 12 inch high output subwoofer
- Exclusive 600W RMS amplifier
- Parallel Drive Technology ™
- ORISUN CORE Direct Servo Technology
- Sealed cabinet design for improved sound quality & subsonics
- Opposed side-firing drivers cancel out cabinet vibration
- Stackable for multiple sub setups
- Outstanding midbass performance
- Dual 1 inch thick grills with acoustically transparent fabric
- Compact CAD designed enclosure
- Precision CNC machined
- Full 1 inch radius corners throughout
- High quality black laminate finish
- RCA and XLR inputs
- 1500W short-term RMS
- Frequency response : 20-300 Hz +/-3.5 dB anechoic
- True 15 Hz or lower in-room extension
- Designed & assembled in our USA factor
Quality enclosure
Our enclosures are very solid and well braced to minimize any cabinet resonances or coloration. The baffle into which the driver is mounted is double thickness.
Our DD+12 subwoofers are exclusively finished in black Grind arenaceous
Bass extension controls
All of our subwoofers feature unique bass extension controls which are not normally provided on subwoofers. This enables the user to customize the output and extension to achieve the best compromise in any room. Most subwoofers neglect to provide bass extension control, and the result is that dynamic headroom is compromised.
Balanced professional version
For professional use, a balanced input version is available. The outputs allow multiple subwoofers to be connected. Simply daisy chain the connections, running output from the first (master) subwoofer to the input of the next. For home use, balanced connections are not normally required. However, for those using studio processors and EQ units with balanced outputs, this option may be more convenient. If connection to a source with RCA connectors as found on my home audio equipment, an adaptor may be used. In this case it should be noted that the connection can no longer be considered balanced. |
PEQ parametric version
There is one band of parametric EQ with adjustable frequency, gain and bandwidth. This means you can not only control the boost or cut, but also the width of the filter. Additional bass management options are also provided. A switch allows the user to select a 12 or 24 db/octave crossover slope setup option. Where the higher slope (24db/octave) is selected, the amplifier uses a variable 12db/octave filter in addition to a fixed 12db/octave filter. One can choose with a switch the corner frequency of the fixed filter as either 50 or 80 Hz, which will suit most situations. The variable filter can be used for fine tuning. |
Orisun DD+12 Specifications | |
| Dual 12" high excursion with custom sensing coil |
| Black or silver anodized aluminum with rubber surround |
| |
| Copper flux modulation shorting rings |
| 600w RMS class A/B patented servo controlled |
| 15-3/4"(W) x 15-3/4" (H )x 17"(D) - (18-1/2" D with grille) |
| |
| 14 - 200 Hz (-2 dB @ 14 Hz) with LFE inputs in A370PEQ3/XLR2/XLR3 |
| 14 - 100 Hz (-2 dB @ 14 Hz) with LINE IN inputs in all models |
| Selectable 12 or 24 dB / octave (PEQ and XLR versions) |
Crossover range (Low pass) | |
Rumble Filter (High pass ) | |
| < 90 degrees phase shift at 20 Hz |
| 0 - 180 degrees continuously variable |
Bass damping factor settings | high (Q=0.5), med (Q=0.7), and low (Q=1.1) |
