代友出美国乐林分体前级

极速旋风 · 发表于 2014-6-22 22:05

您需要登录才可以下载或查看，没有账号？注册

x

Capri Specifications

Overall Gain	14 dB
Gain Range	99.5 dB, 199 Equal Increments
Gain Resolution	0.5 dB, +/-0.03 dB Over Entire Range
Frequency Response	10 Hz - 350 kHz, -3 dB
Maximum Input Level	7 volts RMS at 0 dB Gain
Maximum Output Level	7 volts RMS
THD + Noise	Less than 0.001% , 7 volt output, 20-20kHz.
Signal-to-Noise Ratio	Greater than 100 dB
Output Noise Level	10 Microvolts, Unweighted, 20 Hz to 20 kHz Bandwidth, 0 dB Gain
Common Mode Rejection Ratio	>85dB, 20 Hz 20 kHz
Input Impedance	48K Ohms Balanced or Unbalanced
Channel Separation	>105 dB, 20 Hz to 20 kHz
Inputs	2 x Pair Balanced XLR, 1 x Pair Unbalanced (RCA) Unity Gain (Bypass), 2 x Pair Unbalanced RCA
Outputs	1 x Pair Balanced Line Level, 1 x Pair Unbalanced Line Level
Power Consumption	6 Watts
Weight	9.5 lbs / 4.26 kg
Dimension	2.6”(H) x 13.7” (W) x 6.2” (D) / 6.7 cm (H)x 35 cm (W) x 15.7 cm
