Model | PT-AE7000EH | Power supply | 100–240 V AC, 50/60 Hz | Power consumption | 285 W (0.08 W in standby mode) | LCD*2 panel | Panel size | 18.7 mm (0.74 in) diagonal (16:9 aspect ratio) | Display method | Transparent LCD panel (× 3, R/G/B) | Drive method | Active matrix | Pixels | 2,073,600 (1,920 × 1,080) × 3, total of 6,220,800 pixels | Lamp*3 | 200 W UHM lamp (The lamp replacement cycle is up to 4,000 hours
(lamp power: NORMAL) / 5,000 hours (lamp power: ECO)*4) | Lens | Powered zoom/focus lenses (1.35:1–2.70:1), F 1.9–3.2, f 22.4–44.8 mm | Projection size (diagonal) | 2D projection | 1.02–7.62 m (40–300 inches) | 3D projection | 1.02–5.08 m (40–200 inches) | Throw distance | 1.16–18.08 m (3 ft 10 in to 59 ft 4 in) | Colors | Full color (1,073,741,824 colors) | Brightness*5 | 2,000 lm*6 | Center-to-corner uniformity ratio*5 | 85% | Contrast ratio*5 | 300,000:1*7 (full on/full off) | Resolution | 1,920 × 1,080 pixels | Scanning frequency | RGB | fH: 15 kHz–74 kHz, fV: 24 Hz–85 Hz,
dot clock: 154 MHz or lower | YPBPR (YCBCR) | 525i (480i): fH 15.75 kHz; fV 60 Hz,
525p (480p): fH 31.50 kHz; fV 60 Hz,
750 (720)/60p: fH 45.00 kHz; fV 60 Hz,
1125 (1080)/60i: fH 33.75 kHz; fV 60 Hz,
1125 (1080)/24p: fH 27.00 kHz; fV 24 Hz,
1125 (1080)/50p: fH 56.25 kHz; fV 50 Hz | 625i (576i): fH 15.63 kHz; fV 50 Hz,
625p (576p): fH 31.25 kHz; fV 50 Hz,
750 (720)/50p: fH 37.50 kHz; fV 50 Hz,
1125 (1080)/50i: fH 28.13 kHz; fV 50 Hz,
1125 (1080)/60p: fH 67.50 kHz; fV 60 Hz, | Video/S-Video | fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60]
fH: 15.63 kHz, fV: 50 Hz [PAL/PAL-N/SECAM] | Optical axis shift*8 | Vertical: ±100%, horizontal: ±26% | Keystone correction range | Vertical: approx. ±30°*9 | Installation | Ceiling/desk, front/rear (menu selection) | On-screen menu languages | English, French, German, Spanish, Italian, Chinese, Korean, Russian, Swedish,
Danish, Norwegian, Polish, Czech, Hungarian, Portuguese, Thai, Japanese | Terminals | HDMI IN | HDMI connector × 3, HDMI™ (Deep Color, x.v.Color™*10, CEC*11 ),
HDCP compliant, supports HDAVI Control Version 5 | COMPUTER (RGB) IN | D-sub HD 15-pin (female) × 1 | | RGB signal | R, G, B: 0.7 Vp-p (1.0 Vp-p for sync on G), 75 ohms,
HD/SYNC, VD: TTL (positive/negative polarity compatible)
NOTE: HD/SYNC, and VD terminals do not accept tri-level sync signals. | YPBPR/YCBCR signal | Y: 1.0 Vp-p (including sync signal), PB/PR: 0.7 Vp-p, 75 ohms | COMPONENT IN | RCA pin × 3 (YPBPR/YCBCR) | | Y | 1.0 Vp-p, 75 ohms | PB/CB, PR/CR | 0.7 Vp-p, 75 ohms | TRIGGER IN / TRIGGER OUT /
3D SHUTTER OUT | M3 × 2, 12 V, max. 100 mA
(input/output/3D shutter output selectable using on-screen menu) | VIDEO IN | RCA pin × 1 | S-VIDEO IN | Mini DIN 4-pin × 1 | SERIAL IN | D-sub 9-pin × 1 for external control (RS-232C compliant) | Power cord length | 3.0 m (9 ft 10 in) | Cabinet materials | Molded plastic (PC+ABS) | Dimensions (W × H × D) | 470 mm × 151 mm × 364 mm*12 (18-17/32˝ × 5-15/16˝ × 14-11/32˝)*12 | Weight*13 | Approx. 8.7 kg (19.2 lbs) | Operation noise*5 | 22 dB (lamp power: ECO) | Operating temperature | 0°–40°C (32°–104°F)*14 | Operating humidly | 20%–80% (no condensation) | Remote control unit | Power supply | 3 V DC (AA/R6 type battery × 2) | Operation range*15 | Approx. 7 m (23 ft) when operated from directly in front of the signal receptor | Dimensions
(W × H × D) | 48 × 138 × 28 mm
(1-7/8˝ × 5-7/16˝ × 1-3/32˝) | Weight | Approx. 125 g (4.4 oz) (including batteries) | Supplied accessories | Power cord (× 1) (× 2 for PT-AE7000EA)
Wireless remote control unit (× 1)
Batteries for remote control (AA/R6 type × 2)
Lens cover (× 1) | Optional accessories | Replacement
lamp unit | ET-LAA310 | Ceiling mount bracket | ET-PKA110H (for high ceilings) | ET-PKA110S (for low ceilings) | 3D IR transmitter | ET-TRM110 | 3D Eyewear | TY-EW3D3L (large size)*16
TY-EW3D3M (medium size)*16
TY-EW3D3S (small size)*16 |
*1 Product numbers vary depending on the market. PT-AE7000 is the product number for areas outside of Europe, and PT-AT5000 is the product number within Europe. *2 The projector uses a type of liquid crystal panel that typically consists of millions of pixels. This panel is built with very high-precision technology to provide the finest possible image. Occasionally, a few pixels may remain turned on (bright) or turned off (dark). Please note that this is an intrinsic characteristic of the manufacturing technology that affects all products using LCD technology. *3 The projector uses a high-voltage mercury lamp that contains high internal pressure. This lamp may break, emitting a large sound, or fail to illuminate, due to impact or extended use. The length of time that it takes for the lamp to break or fail to illuminate varies greatly depending on individual lamp characteristics and usage conditions. *4 The values above are maximum values when they are used in cycles of being turned on for 2 hours and off for 0.25 hours. When the lamps are turned on and off more frequently, the lamp replacement cycle is shortened. The usage environment affects the lamp replacement cycle. *5 Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards. *6 In dynamic mode, with dynamic iris on. *7 In cinema 1 mode, with dynamic iris on. *8 Shift range is limited during simultaneous horizontal and vertical shifting. *9 When a 3D signal is being input or when a 2D signal is converted to 3D, the keystone correction does not function. *10 Effective in Rec. 709 picture mode. *11 CEC is an abbreviation for Consumer Electronics Control. Operation may not be possible with some connected equipment or settings. *12 With legs at shortest position. *13 Average value. May differ depending on models. *14 When [HIGH ALTITUDE MODE] is set to [ON]: 0°C – 35°C (32°F–95°F) *15 Operation range differs depending on environments. *16 If you do not have a Panasonic 3D TV that supports 3D video, use a SANYO eneloop Mobile Booster KBC-L2 series to charge your Eyewear.
The code that follows KBC-L2 may differ depending on the country of purchase. The code at the end of the model number of 3D Eyewear may
differ depending on the country of purchase.
|
